It will be displayed in the BOM, where you can check it.

Add a PHOENIX CONTACT, SINGLE PHASE DIN RAIL POWER SUPPLY with a 0.75 A, 24VDC rating into the Catalog Browser.Ģ.

Finally, you will add the power supply footprints over a DIN rail, as shown in the illustration below.Ī summarized version of the various tasks and steps in the practice are provided below. You will also create a new footprint and add the footprint block link to the Footprint database. In Chapter 10 of the learning guide, in Practice 10 e: Footprint Database, you will learn to add a new component to the BOM database. Now the practice flows better with respect to the rest of practices in the above mentioned chapter. I have replaced the Footprint Database practice with a new practice to incorporate a real-world example from the Electrical industry which both the Instructors and students will relate to.

This year, in addition to incorporating the regular updates, one major change to the learning guide is the redesign of a practice in Chapter 10: Symbol Creation. I am pleased to announce that ASCENT’s AutoCAD Electrical 2019: Fundamentals with NFPA Standardslearning guide is now available for you to start teaching and learning from. I know many of you are waiting for our latest learning guide on AutoCAD Electrical 2019 software.
